● Analytical Chemistry: Storing standards and samples for trace analysis in Chromatography, Mass Spectrometry, ICP-MS, etc.
● Semiconductor & Electronics: Containing ultra-pure chemical reagents, such as high-purity etchants and photoresists.
● Biotechnology: Preserving biochemical samples sensitive to container surfaces, such as enzymes, proteins, and nucleic acids.
● Pharmaceutical Industry: Storing API intermediates requiring high compatibility.
● Hazardous Chemical Handling: Safely storing and transferring highly corrosive chemicals like hydrofluoric acid.
A PTFE bottle is more than just a container; it is a guarantee of purity, stability, and reliability. When your application involves the most sensitive analyses, the most aggressive chemicals, or the most stringent purity requirements, PTFE bottles provide an irreplaceable, perfect solution. They are the trusted choice for scientists and engineers who pursue precision and quality.
1.Material: PTFE
2.Capacity: 25ml/50ml/100ml/150ml/200ml/250ml/500ml/1000ml/2000ml
3.Color: Pure White
4.Working temperature: 200℃~ +260℃
5.Do not get close to fire, should be used on asbestos plate
|
Product name |
PTFE Bottles |
|
Application |
Laboratory, chemical |
|
Material |
PTFE |
|
Color |
White |
|
Specification |
25ml~ 2000ml |
|
Processing Service |
Moulding |
|
Place of Origin |
Zhejiang, China |
|
Design |
OEM Acceptable |
|
Packing |
Carton |
|
Feature |
High Temperature Resistance |
|
Characteristic |
Strong Acid and Alkali Resistance |
|
Packaging Details |
1. Standard carton package 2. Support customization |
|
Port |
Ningbo/ Shanghai |
|
PTFE Crucible |
Model No. |
Volume |
Mouth inner diameter |
Body diameter(mm) |
Height with cap(mm) |
|
|
CL-NM50 |
50ml |
21 |
51 |
97 |
|
CL-NM100 |
100ml |
21 |
52 |
103 |
|
|
CL-NM150 |
150ml |
21 |
54 |
108 |
|
|
CL-NM200 |
200ml |
34 |
68 |
114 |
|
|
CL-NM250 |
250ml |
34 |
69 |
118 |
|
|
CL-NM500 |
500ml |
34 |
81 |
148 |
|
|
CL-NM1000 |
1000ml |
41 |
100 |
190 |
|
|
CL-NM2000 |
2000ml |
56 |
140 |
230 |
|
PTFE Crucible |
Model No. |
Volume |
Mouth inner diameter |
Body diameter(mm) |
Height with cap(mm) |
|
|
CL-WM25 |
25ml |
21 |
35 |
77 |
|
CL-WM50 |
50ml |
35 |
50 |
92 |
|
|
CL-WM100 |
100ml |
35 |
51 |
105 |
|
|
CL-WM150 |
150ml |
35 |
55 |
108 |
|
|
CL-WM200 |
200ml |
41 |
68 |
114 |
|
|
CL-WM250 |
250ml |
41 |
69 |
118 |
|
|
CL-WM500 |
500ml |
41 |
80 |
150 |
|
|
CL-WM1000 |
1000ml |
47 |
100 |
190 |
|
|
CL-WM2000 |
2000ml |
64 |
140 |
230 |
